SANNCE 8CH 5MP DVR CCTV System 5MP 1080P Security Cameras IR Outdoor IP66 Video Surveillance Kit Motion Detection 3.6MM Lens
1.If you don't purchase a hard disk,you can't record and review the video.
2.If you purchase a package with a hard disk, the hard disk may be placed directly in the DVR or placed separately in the package. If you have any questions, please contact us.
3.Our 8CH DVR can connect 8 cameras max, so you can add extra cameras in the future.
Package Contents
4 X Camera ( no cable for United Kindom Warehouse)
8CH 4PCS DVR Kit Pakcage Include:
1X DVR
4XCameras
4X 60 ft/18.3 m BNC Cables
2XPower Adapters
1X1-TO-4 Splitter Cable
1X USB Mouse
5X Window Warning Stickers
1X User Manual
4X Mounting Screw Bags
8CH 8PCS DVR Kit Pakcage Include:
1X DVR
8XCameras
8X 60 ft/18.3 m BNC Cables
3XPower Adapters
2X 1-TO-4 Splitter Cable
1X USB Mouse
9XWindow Warning Stickers
1X User Manual
8X Mounting Screw Bags
5MP HD Camera | ||
Camera | Video Resolution | AHD 5MP(12.5&20 Frame ) |
Signal system | PAL/NTSC | |
Image sensor | Progressive Scan CMOS | |
Lens | 3.6mm | |
Min.Illumination | 0.02Lux@(F1.2 AGC ON),0Lux with IR on | |
Angle of View | 70° | |
Number of Infra-Red LEDs | 12 | |
Night Vision Distance | Up to 100ft/30m | |
DNR | 3D DNR | |
Wide Dynamic Range | Digital WDR | |
IR Cut Filter | Yes | |
Video Output | HD BNCx1 | |
General | Housing | Plastic |
Color | Black | |
Operating Power | DC12V | |
Operating Temperature | -4 °F – 140 °F /-20 °C – 60 °C | |
Indoor/Outdoor | Indoor/Outdoor | |
Weatherproof Rating | IP66 | |
Dimension (L x W x H) | 6.49' x2.36' x 2.36' / 165 x 60 x 60mm | |
Weight | 0.33lbs / 150g | |
1080P HD Camera | ||
Camera | Video Resolution | HD 1080P |
Signal system | PAL/NTSC | |
Image sensor | Progressive Scan CMOS | |
Lens | 3.6mm | |
Min.Illumination | 0.02Lux@(F1.2 AGC ON),0Lux with IR on | |
Angle of View | 70° | |
Number of Infra-Red LEDs | 12 | |
Night Vision Distance | Up to 100ft/30m | |
DNR | DNR | |
Wide Dynamic Range | Digital WDR | |
IR Cut Filter | Yes | |
Video Output | HD BNCx1 | |
General | Housing | Plastic |
Color | Black | |
Operating Power | DC12V | |
Operating Temperature | -40 °F – 140 °F /-40 °C – 60 °C | |
Indoor/Outdoor | Indoor/Outdoor | |
Weatherproof Rating | IP66 | |
Dimension (L x W x H) | 6.49' x2.36' x 2.36' / 165 x 60 x 60mm | |
Weight | 0.33lbs / 150g | |
1080P DVR | ||
Video & Audio | Codec | H.264+ |
Video input | 8*BNC | |
HDMI output | 1*HDMI (MAX:1080P) | |
VGA output | 1*VGA (MAX:1080P) | |
Audio I/O | 1/1 | |
Encode | 8*1080N@15fps | |
Decode | 4*1080N@15fps | |
Multi-mode | Analog: 8*1080N@15fps;4*5M-N(21fps) | |
Hybird: 8*1080N@15fps(analog)+2*1080P | ||
IP: 16*1080P；16*5MP | ||
Playback | 4CH (Analog mode) | |
Compression | G.711a | |
Intercom | Support | |
Hard Drive | HDD | 1*SATA interface |
HDD Capacity | Up to 8TB Capacity | |
Management | Record mode | Manual>Motion detection>Schedule |
Inquire mode | Inquire by Time/Calendar/Event/Channel | |
Storage mode | Sata HDD | |
Backup | Network, USB storage | |
External Interface | Ethernet port | 1*10/100Mbps Ethernet port, RJ45 port |
Alarm I/O | / | |
PTZ control | / | |
USB Port | 2*USB2.0 ports | |
General | Power supply | 12V/2A |
Consumption | <10W(Without HDD) | |
Temperature | 0℃- + 55℃ | |
Humidity | 10% -90% RH | |
Dimension | 255(L)* 236mm(W)* 44mm(H) | |
Weight | Around 1KG | |
5MP DVR | ||
Video & Audio | Codec | H.264+ |
Video input | 8*BNC | |
HDMI output | 1*HDMI (MAX:1080P) | |
VGA output | 1*VGA (MAX:1080P) | |
Audio I/O | 2/1 | |
Encode | 8*5MN@15fps | |
Decode | 4*5MN@15fps | |
Multi-mode | Analog: 8*5MN@15fps; | |
Hybird: 8*5MN@15fps(analog)+4*1080P | ||
IP: 16*1080P；16*5MP | ||
Playback | 4CH (Analog mode) | |
Compression | G.711a | |
Intercom | Support | |
Hard Drive | HDD | 1*SATA interface |
HDD Capacity | Up to 8TB Capacity | |
Management | Record mode | Manual>Motion detection>Schedule |
