Dahua IPC-HDW3849H-AS-PV-S4 8MP 4K Smart Dual Light Full-Color Wizsense IP Camera 2-Way Audio Active Deterrence Security Camera
Dahua IPC-HDW3849H-AS-PV-S4 8MP 4K Smart Dual Light Full-Color Wizsense IP Camera 2-Way Audio Active Deterrence Security Camera
![]()
* The parameters and datasheets below can only be applied to 3849-PV-S4 series.
· 8-MP 1/2.8" CMOS image sensor, low luminance, and high definition
image.
· Outputs max. 8 MP (3840 × 2160)@25/30 fps.
· H.265 codec, high compression rate, ultra-low bit rate.
· Built-in warm light and IR LED; the max. IR illumination distance is 30 m
and warm light distance is 30 m.
· ROI, SMART H.264+/H.265+, AI H.264/H.265, flexible coding, applicable
to various bandwidth and storage environments.
· Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable
to various monitoring scenes.
· Intelligent monitoring: Intrusion, tripwire (the two function support the
classification and accurate detection of vehicle and human).
· Abnormality detection: Motion detection, privacy masking, scene
changing, audio detection, no SD card, SD card full, SD card error,
network disconnection, IP conflict, illegal access, and voltage detection.
· Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 256 G Micro SD
card; built-in dual MICs; 1-ch speaker; support two-way talk.
· 12 VDC/PoE power supply.
· IP67 protection.
· Sound and light alarm (red and blue lights).
· SMD 4.0.
· One press arming/disarming through alarm input.
![]()
![]()
![]()
![]()
![]()
Model: IPC-HDW3849H-AS-PV
1.Camera :
Image Sensor : 1/2.8'8Megapixel progressive CMOS
Max. Resolution : 3840(H) × 2160 (V)
ROM : 128 MB
RAM : 512 MB
Scanning System : Progressive
Electronic Shutter Speed : Auto/Manual 1/3 s–1/100,000 s
Min. Illumination : 0.007 Lux @ F1.4
S/N Ratio : > 56 dB
Illumination Distance : 30 m (98.4 ft)
Illuminator On/Off Control : Auto/Manual
Illuminator Number : 1 (Warm light)
Pan/Tilt/Rotation Range : Pan: 0°–360°;Tilt: 0°–78°;Rotation: 0°–360°
2.Lens :
Lens Type : Fixed-focal
Mount Type : M12
Focal Length : 2.8 mm; 3.6 mm
Max. Aperture : F1.4
Field of View : 2.8 mm: Horizontal 107° × Vertical 56° × Diagonal 127°;3.6 mm: Horizontal 89° × Vertical 46° × Diagonal 102°
Iris Type : Fixed
Close Focus Distance : 2.8 mm: 1.5 m (4.9 ft);3.6 mm: 2.2m (7.2 ft)
3.Professional, intelligent :
IVS (Perimeter Protection) : Tripwire; intrusion (support the classification and accurate detection of vehicle and human)
Intelligent Search : Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos.
4.Video :
Video Compression : H.265; H.264; H.264H; H.264B; MJPEG(only supported by the sub stream)
Smart Codec : Smart H.265+/Smart H.264+
Video Frame Rate : Main stream:3840 × 2160 @(1–20 fps by default);3840 × 2160 @(1–25/30 fps with AI function disabled);sub stream: 704 × 576 @ (1–25 fps)/704 × 480 @ (1–30 fps);third stream:1280 × 1080 @ (1–25/30 fps)
Stream Capability : 3 streams
Resolution : 8M (3840 × 2160); 6M (3072 × 2048); 5M (3072 × 1728/2592 × 1944); 4M (2688 × 1520); 3M (2048 × 1536/2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1(704 × 576/704 × 480);VGA (640 × 480); CIF (352 × 288/352 × 240)
Bit Rate Control : CBR/VBR
Video Bit Rate : H.264: 32 kbps–8192 kbps;H.265: 12 kbps–8192 kbps
Day/Night : Color/B/W
BLC : Yes
HLC : Yes
WDR : 120 dB
Scene Self-adaptation (SSA) : Yes
White Balance : Auto/natural/street lamp/outdoor/manual/regional custom
Gain Control : Auto/Manual
Noise Reduction : 3D NR
Motion Detection : OFF/ON (4 areas)
Region of Interest (RoI) : Yes (4 areas)
Smart Illumination : Yes
Image Rotation : 0°/90°/180°/270° (Support with 1920 × 1080 resolution and lower)
Mirror : Yes
Privacy Masking : 4 areas
5.Audio :
Built-in MIC : Yes
Audio Compression : PCM, G.711a, G.711Mu, G726
6.Alarm :
Alarm Event : No SD card; SD card full; SD card error; service life warning (supported by DH card); network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; audio detection; voltage detection; external alarm; SMD; safety exception; light alarm; sound alarm (11 built-in sounds and custom voices importing)importing)
7.Network :
Network : RJ-45 (10/100 Base-T)
SDK and API : Yes
Protocol : IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP
Cyber Security : Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade
Interoperability : ONVIF (Profile S/Profile G/Profile T); CGI; Milestone; Genetec; P2P
User/Host : 20 (Total bandwidth: 80 M)
Storage : FTP; SFTP; Micro SD card (support max. 256 G); NAS
Browser : IE: IE8 and later/Chrome/Safari: Safari 12 and later/Firefox
Management Software : Smart PSS; DSS; DMSS
Mobile Phone : IOS; Android
8.Certification :
Certification : CE-LVD: EN62368-1;CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU;FCC: 47 CFR FCC Part 15, Subpart B
9.Port :
Audio Input : 1 channel (RCA port)
Audio Output : 1 channel (RCA port)
Alarm Input : 1 channel in: 5mA 3V–5V DC
Alarm Output : 1 channel out: 300mA 12V DC
10.Power :
Power Supply : 12V DC/PoE (802.3af)
Power Consumption : Basic power consumption: 3.1W (DC12V); 3.5W (POE)Max. power consumption (WDR + H.265 + red and blue lights flashing alternately + warm light + sound alarm): 7.8W (DC12V); 8.2W (POE)
11.Environment :
Operating Conditions : –40°C to +60°C (–40°F to +140°F)/Less than 95% RH
Storage Conditions : –40°C to +60°C (–40°F to +140°F)
Protection Grade : IP67
12.Structure :
Casing : Metal
Dimensions : Φ122.0 mm × 110.9 mm (4.8" × 4.4")
Net Weight : 754 g (1.7 lb)
Gross Weight : 915 g (2.0 lb)
Packing-List :
1. IPC-HDW3849H-AS-PV-S4 8MP 4K Smart Dual Light Full-Color Wizsense IP Camera
2. 1x User manual .
3. 1x Waterproof plug .
4. Installation tool .
5. 1x screws bag.
6. 1x Drill Template .
