Home > ANNKE 8CH 5MP Lite Video Surveillance System 5IN1 H.265+ DVR With 4X 5MP PIR Detection Dome Waterproof Security Cameras CCTV Kit

ANNKE 8CH 5MP Lite Video Surveillance System 5IN1 H.265+ DVR With 4X 5MP PIR Detection Dome Waterproof Security Cameras CCTV Kit

$214.30
ANNKE
D0102HEKB6P
Add to Cart
Details:
*High quality imaging with 3K, 2960 × 1665 resolution
*2.8 mm fixed focal lens@F1.2
*High quality audio with audio over coaxial cable, built-in mic
*Up to 30m IR distance for bright night imaging
*Up to 20 m white light distance for bright night imaging
*One port for four switchable signals (TVI/AHD/CVI/CVBS)
*Water and dust resistant (IP67)
· 5MP high definition live viewing
· 5MP Lite recording & playback
· Advanced H.265+ Video Compression
· Human and Vehicle detection, Deeping learning technology
· Support TVI/AHD/CVI/CVBS/IPC input. 5 in 1
· Supports iPhone, iPad, Android mobile remote monitoring



DVR

Video & Audio

Video Compression

H.264+/H.264/H.265/H.265+

Video Input

8CH Analog HD/Analog + 2CH IP camera

Video Output

HDMI and VGA up to 1080p

Audio Input/Output

1/1 RCA

Supported Camera Types

Support HD TVI Input: 5MP, 4MP, 3MP, 1080p@30 fps, 1080p@25 fps, 720p@60 fps, 720p@50 fps, 720p@30 fps, 720p@25 fps;
Support AHD Input: 4MP, 1080p@25 fps, 1080p@30 fps, 720p@25 fps, 720p@30 fps;
Support CVI Input: 4MP, 1080p@25 fps, 1080p@30 fps, 720p@25 fps, 720p@30 fps;
Support CVBS Input

Analog HD Playback Resolution

5MP Lite/@12fps, 4MP Lite/1080p/720p/@15 fps,
VGA/WD1/4CIF/CIF@25 (30) fps

IPC Recording Resolution

Up to 6MP

IPC Playback Resolution

Up to 6MP

Max. Playback Channel

2-CH

Deep learning

Human and Vehicle detection

ONVIF Protocols

Support

Hard Drive

HDD

1 SATA Interface

HDD Capacity

Up to 6 TB Capacity

External Interface

Network interface

RJ45 X1(10/100 M)

BNC Output

－

Alarm Input/Output

－

RS485

－

USB

USB 2.0 X2

General

Operating Power

DC 12 V

Working Temperature

-14 °F – 131 °F/-10 °C – 55 °C

Dimensions (W X H X D)

260 X 222 X 45 mm

Weight (Without Hard Disk)

≤1 kg (2.2 lbs.) (Without HDD)







Model Number

CR1BN

HD Camera

Camera

Image Sensor

5MP CMOS Image Sensor

Video Resolution

2560 (H) X 1944 (V)

Signal System

PAL/NTSC

Frame Rate

PAL: 5MP@20 fps, 4MP@25 fps, 1080p@25 fps
NTSC: 5MP@20 fps, 4MP@30 fps, 1080p@30 fps

Lens

2.8 mm

Min. Illumination

Color: 0.01 Lux@(F1.2, AGC On), 0 Lux with IR

Angle of View

85.5°

Number of Infrared LEDs

1

PIR Detection

Support

Visual Alarm

White Light

OSD Menu

Yes

Night Vision Distance

Up to 100 ft/30 m

DNR

Support

Wide Dynamic Range

Digital WDR

IR-Cut Filter

Yes

Video Output

HD BNC X1

General

Material

Plastic

Color

White

Operating Power

DC 12 V

Operating Temperature

-40 °F – 140 °F/-40 °C – 60 °C

Indoor/Outdoor

Indoor/Outdoor

Weatherproof Rating

IP67

Dimension (L X W X H)

Φ4.32' X 3.53'/Φ109.8 X 89.75 mm

Weight

0.53 lb./242 g
