ANNKE 8CH 5MP Lite 5in1 HD TVI CVI AHD IP Security DVR Recorder H.265+ Video Recorde Email Alert Motion Detection
Note:
This type of DVR just support 'ANNKE' Brand Wired Camera,please notice it!If you still have any problems with the item please contact us directly.
Key Features:
· 5MP High Definition Live Viewing
· 5MP Lite Recording & Playback
· Revolutionary H.265 Pro+ Codec
· Support TVI/AHD/CVI/CVBS/IPC Input
· Supports iOS/Android Mobile Remote Monitoring
Specifications:
Video Compression: H.265+
Video Input: 8CH Analog HD/Analog+2CH IP camera
Video Output: HDMI and VGA Up to 1080P
Analog HD Playback Resolution: 5MP Lite/3MP/1080p/720p/VGA/WD1/4CIF/CIF@12fps
IPC Recording/Playback Resolution: Up to 2M (1920x1080)@30fps
Max Playback Channel: 8 Channels
HDD Interface: 1 SATA Interface
HDD Capacity: Up to 6TB Capacity
Network Interface: RJ45x1 (10/100M)
Operation Power: DC12V
Working Temperature: -10 °C – 55 °C (-14°F – 131 °F)
What's in the Box?
* 1× DVR
* 1× 5.9ft/1.8m HDMI Cable
* 1× 3.2ft/1m Ethernet Cable
* 1× Power Adapter
* 1× USB Mouse
* 1× User Manual
Product Description:
This powerful 5-in-1 DVR system is an ideal solution for your home and business surveillance. Built with the most advanced H.265+ coding standard, it enables you to record up to 7 times longer than the common H.264, thus saves you substantial storage cost. Because of its strong compatibility, you can more 5MP cameras to it for ultra HD video playback.
* State-Of-The-Art H.265 Pro+ Codec
Revolutionary H.265 pro+ coding enables stable real-time viewing without block, save your time from intermittent transmission and video loading. It records up to 98 days continuously for 4 cameras simultaneously with a 1TB HDD, which is 7 times of H.264, saving cost of extra HDD.
* 5-IN-1 DVR Supports 5MP HD Input
This powerful DVR supports up to 8 CVI/CVBS/AHD/TVI cameras and 2 IP cameras, covers every corner and brings you peace in mind. It can be connected to 5MP HD cameras for up to 5MP ultra HD resolution in live viewing and 5MP Lite in video playback.
* Easy Remote Access & Real-time Alerts
You can have access to the system via iOS/Andriod phone, tablet and PC, keeping everything under control no matter where you are. It will also send real-time email alerts with snapshots and APP alarm pushes once alert is triggered, so you can take appropriate precautions
* Save Time with Smart Search/Playback
The smart playback feature fast-forwards the still images and offers you video with movements in selected areas and period. Thus you don't have to waste time on checking footage frame by frame. It is much easier to find what you need in the records.
* Privacy Protected and Worry-Free Warranty
All our products are CE, FCC and HDMI certified. You could set password and encryption code for access restrictions, avoiding privacy disclosure. We also provide professional lifetime technic support on ANNKE help center, 3-year warranty and 90-day money back guarantee.
DVR | ||
Video & Audio | Video Compression | H.264+/H.264/H.265/H.265+ |
Video Input | 8CH Analog HD/Analog + 2CH IP Video (up to 12 channel when IP enhanced mode on) | |
Video Output | HDMI and VGA Up to 1080P | |
Audio Input | 1-ch RCA,8-ch via coaxial cable | |
Audio Output | 1-ch RCA | |
Supported Camera Types | Support HD TVI Input: 3K/5MP@20FPS, 4MP, 3MP, 1080p, 720p; | |
Analog HD Playback Resolution | 3K Lite/5MP Lite/4MP Lite@12fps,1080p/720p@15fps | |
IPC Playback Resolution | Up to 6MP | |
Max Playback Channel | 2-ch | |
Protocols | TCP/IP, PPPoE, DHCP, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS | |
Motion Detection 2.0 | All analog channels support human and vehicle detection to reduce false alarm | |
Hard Drive | HDD | 1 SATA interface |
HDD Capacity | Up to 10TB capacity | |
External Interface | Network interface | 1, RJ45 10M/100M self-adaptive Ethernet interface |
USB | USB2.0x2 | |
General | Operating Power | DC12V,≤ 12W (without HDD) |
Working Temperature | -14 °F – 131 °F /-10 °C – 55 °C | |
Dimensions(W x H x D) | 260 × 222 × 45 mm (10.2 × 8.7 × 1.8 inch) | |
Weight (without hard disk) | ≤ 1 kg (2.2 lb)(without HDD) | |
