8MP Hikvision Compatible IP Camera PoE IR Colorful Night Vision 5MP CCTV Security Camera Plug&Play with HIK NVR app view
[About Functions] please check the item model number and descriptions firstly. Or please contact us soon if there is some uncertainty about item, we will do our best to help you.
[About information of order] the order's information are very important; so please leave correct address, phone number, zip code with your order. We only send the package to the address that you left. And the address can not be changed after you pay.
As different country has different shipping rules.We will choose the express method for you according to our experience. Besides,if your shipping cost is too high,Hope you kindly understand that we could not remove the shipping cost for you.
We suggest you use this camera with HIK NVR ,you will enjoy a better experience .
5MP Model PG2355I/PG2357C | 8MP Model PG2385I/PG2387C |
·IR : 1/2.8" CMOS Sensor | ·IR : 1/2.8" Sony CMOS Sensor |
·ColorVu : 1/2.8"Sony CMOS Sensor | · ColorVu : 1/2.8"Sony Ultra CMOS Sensor |
· Day/Night(ICR), Ultra DNR | · Day/Night(ICR), Ultra DNR |
· MAX. 30fps 5MP(2592 × 1944) | · Max. 20fps 8MP |
· H.265/H.264 dual-stream media server | · H.265/H.264 dual-stream media server |
· Compatibility: HIK,ONVIF, RTSP | · Compatibility: HIK,ONVIF, RTSP |
· Multi web browser, PC Client, mobile APP remote access | · Multi web browser, PC Client, mobile APP remote access |
· Support PoE | · Support PoE |
· IP66 waterproof | · IP66waterproof |
· built-in MIC | · built-in MIC |
Camera:PG23X5I(IR)/PG23X7C(ColorVu)
Image Sensor:
5MP:1/2.8" CMOS Sensor ;
8MP:1/2.8" Sony CMOS Sensor ;
Min. Illumination
IR: Color: 0.1 Lux(F2.0, AGC ON) B/W:0.004 Lux(F2.0, AGC ON)0 Lux with IR ;
ColorVu : Color: 0.01 Lux @(F1.0, AGC ON),0 Lux with Light
White Balance:Auto/Manual/ATW (Auto-tracking White Balance)/Indoor/Outdoor/Fluorescent Lamp/Sodium Lamp
Gain:Auto/Manual
Shutter Speed:1/10 s to 1/10,000 s
Day & Night:IR or ColorVu
Privacy Mask:4 programmable privacy masks
Lens
Focal Length:2.8 mm (3.6mm Optional)Horizontal field of view: 103°
Field of View:Vertical field of view: 59° Diagonal field of view: 118°
Compression Standard
Video Compression:Main Stream: H.265+,H.265,H.264Sub-stream:H.265+,H.265,H.264
H.265 Type:Baseline profile/Main profile/High profile
Event
Basic Event:Motion Detection,Human Detection / Vehicle Detection
IR
IR Distance:IR LEDs or Warm white LEDs, up to 30m
IR LED:2PCS
Max. Resolution:5MP:2592 × 1944;8MP:3840 x 2160
Main Stream:5MP:30fps 5MP(2592 × 1944)8MP:20fps 8MP(3840 x 2160)
Sub-Stream:5MP:D1/VGA/640x360/CIF 25fps, etc;8MP:VGA/640x360/480X360P/CIF 25fps, etc
Image Enhancement:BLC/3D DNR/HLC/WDR
Network
Ethernet:RJ-45 (10/100Base-T)
Protocols:IPv4/IPv6, HTTP/RTSP/FTP/NFS/SMTP/DHCP/NTP/TCP/IP, etc.
API:ONVIF (Profile S, Profile G, Profile T),HIK
Simultaneous Live View:Up to 20 channels
Client:AjDevTool,SADP, Danale App,LMS,iVMS-4200
Web Browser:IE 8+ ,Chrome 57.0+, Firefox 52.0+
Interface
Network Interface:1 RJ45 10 M/100 M Ethernet,PoE
Power:12 VDC or POE
General
Language (Web Browser Access ):7 languages:Chinese, English, Russian,German, Italian, , Turkish, 한국어
Power:12 VDC, 1.5 A (Max. 10.9 W, including Max. 4.2 W for IR);PoE (802.3af), 36 to 57 VDC, 0.35 A (Max. 12.2 W, including max. 4.2 W for IR)
Working Environment
Temperature: -20°C to 60°C (-4°F to 140°F), humidity: ≤ 90%
Protection Level:IP67 standard
Material:Aluminum alloy
Dimension:Φ 110 mm × 87.5 mm (Φ 4.33" × 3.44")
Weight:Approx. 0.59 kg (1.3 lb.)
Built-in Mic
Support one way audio Recording
Human and Vehicle Detection
Easy to Set-up,Play&Plug with Hikvison NVR
Pack List:
1. 2/5/8MP IPC*1
2. Waterproof accessories *1
3. Screw*1lot
HIK Tool - IVMS-4200
